how to repair flat die pellet machine

Small flat die pellet press is very common in life, but for investment, many people will consider some aspects: 1. Worry about high investment, high production costs, increased labor and power consumption. 2. Worry about the skills of personnel can not operate pellet press.

There is no need to worry about these problems at all. First of all, for flat die pellet press, they are low-cost, easy to operate, require less labor, and raw materials are quite common, such as waste crops, straw, corn straw, grass, etc. Or other common agricultural waste, anyone can easily get it.

Second, for technical issues, manufacturers can provide you with mechanical manuals and operational skills training, as well as after-sales service. At this point, our company does very well, we can work on-site guidance work, the following points for the user should pay attention to the daily operation of pellet press.

Repair and replace ring dies,rollers and sieve. The sieve is punched with steel or iron plates. When the sieve is worn or damaged by certain materials, if the damaged area is not large, it can be added by riveting or soldering. If the damaged area is large, the sieve must be replaced. When changing sieves, make sure the smooth side faces outward, and the sieve with a screen mesh must be sealed.
Replace pellet grinder and hammer. For the broken part, the hammer is a fast wear part, and is also the main part of the final particle quality and yield production. Teeth claws and hammers must be replaced in time.
To replace the claw, remove the round nut locking plate on the back or disk, tighten the nut with a hook screw, and pull the disc out. In order to keep the rotor working stably, the teeth must be completely replaced, the change must be static balance test, and for the claw, the nut must be tightened, and the washer should be put back, and the standard tooth section should be selected. Each weight is less than 1.0-1.5 g.
Pellet press bearing lubrication and replacement.
The crusher needs to be cleaned after 200 hours, and the bearings must be cleaned. If the bearings are lubricated, add new oil and make sure the bearing seat is filled with one third, not more than a quarter of a percent.
Before slightly opening the oil cup cover, when the crusher bearing is worn, it must be replaced and lubricated in time. For the tapered roller bearings, the axial space must be checked to keep it at 0.1-0.3 mm, if there is a problem, Can be adjusted by increasing or reducing the bearing cover pad.
